New SMEC SL 1000GB | CNC Lathes

Capacity
Swing Over the Bed 39.38″
Swing Over the Cross Slide 32.29″
Max. Grinding Diameter 32.29″
Max. Grinding Length 13.39″

Spindle
Spindle speed 1,000 rpm
Spindle Nose A2-6
Spindle Bore 3″
Main Spindle motor (Cont./Max) 10.06/14.76

Travel
Axis Travel (X/Z) 20.08″/19.69″
Guide ways Box Guide
Rapid Traverse Rate (X/Z) 629.93/629.93 inch/min

Grinding Spindle
Spindle Speed 6,000 rpm
Spindle Motor (cont/max) 3.7/5.5 hp Tool Shank Type BBT40
Spindle Lubrication and Cooling Grease encapsulation

ATC (Optional)
Max Number of Tools 2
Tool Change Method Double Arm Swing

General
Floor Space (L×W) 102.09″ x 78.86″
Machine Weight A [B] 10,803 lbs.
Controller Fanuc 0i-TF+
